A sprinter wide look kit does not have to mean a full body kit replacement. You can achieve a broader, more aggressive stance on your Mercedes Sprinter by combining arch flares, side skirts, and matching trim pieces, keeping your factory bumpers intact and cutting cost and installation time significantly. At DL Auto Design we manufacture and supply these modular wide body styling components for Sprinter W906, W907, and W910 platforms, shipped worldwide from our facility in Lithuania.

What Is a Sprinter Wide Look Kit and What Does It Include?

A wide look kit is a curated selection of bolt-on exterior parts that together create the visual impression of a wider, lower, more purposeful van without replacing every panel on the vehicle. The core pieces are fender arch flares, side skirts, and optionally a rear diffuser or bumper add-on. Each part is designed to work alone or as a set, which is why this approach suits builders who want incremental upgrades rather than a single large-budget project.

The typical components in a modular sprinter wide look kit are listed below, ordered by visual impact.

• Wheel arch flares - extend the bodywork over wider wheels and give the most immediate wide-body effect
• Side skirts - close the gap between the arch flares front and rear and lower the visual centre of gravity
• Rear bumper add-ons or diffusers - finish the wide stance at the back and tie together the side treatment
• Front lip or bumper upgrade - optional but recommended to balance the wider profile at the nose

Sprinter Fender Flare Kit: Fitment by Generation and Wheelbase

Fitment is the most critical question before ordering any wide body styling for a Sprinter. The W906 (2006-2018, known as NCV3 in North America) and the W907/VS30 (2018-present) are completely different platforms with different arch openings, door lines, and sensor positions. Parts are not interchangeable between generations.

Within each generation, wheelbase matters for side skirts because the sill length differs between short-body (L1/L2) and long-body (L3/L4) vans. Always confirm your wheelbase code before ordering. If you are unsure, the chassis plate behind the driver-side door lists the wheelbase in millimetres, which corresponds to the L-code.

Our Mercedes Sprinter W907 arch flares are manufactured to fit the 2018-to-present VS30/W907 body line precisely, covering the gap created by aftermarket wheel spacers or wider tyre profiles without requiring permanent sheet metal modification on most fitments.

Materials: ABS Plastic vs Fiberglass for Wide Body Styling

At DL Auto Design we offer arch flares and side skirts in two primary materials: ABS thermoplastic and fiberglass-reinforced plastic (FRP). Each has real-world advantages that depend on how the van is used.

ABS plastic is impact-resistant, flexes slightly on contact rather than cracking, and holds paint well. It is the preferred material for commercial vans, camper builds, and any application where the vehicle is driven daily over varied terrain. ABS parts are also generally lighter, which matters for payload-rated vehicles.

Fiberglass (FRP) allows more complex surface detail and a smoother factory-grade surface finish out of the mould. It is favoured for show-standard builds, luxury shuttle conversions, and executive transport where surface perfection is the priority. FRP is slightly more rigid, so installation alignment must be precise.

Both materials are supplied paint-ready with a primer base. We also offer pre-painted options for customers who provide a RAL or Mercedes paint code, which eliminates the need for a body shop step before fitting.

How to Achieve the Wide Look Without Replacing the Bumpers

The most cost-effective route to wide body styling on a Sprinter is to fit arch flares and side skirts while keeping the factory or existing aftermarket bumpers. This works because the visual widening happens at the mid-section of the vehicle, which is the area that draws the eye when the van is viewed from the front quarter or the rear quarter.

The process in practical steps:

1. Measure the existing tyre and wheel combination to determine how much arch extension is needed - typically 20 mm to 40 mm per side for a natural look
2. Order arch flares sized for your wheelbase and confirm sensor cutout requirements if your Sprinter has front or rear parking sensors or a 360-degree camera system
3. Dry-fit the flares before any bonding to check alignment with the door line and existing body creases
4. Fit side skirts from the same design family so the shadow line from arch to arch is continuous
5. Prime, colour-match paint to your van, and lacquer before final installation
6. Seal all edges with flexible body sealant to prevent water ingress and stone chip lifting

The result is a wide look that appears factory-integrated because the bumpers, which pedestrians and cameras recognise first, remain unchanged. This also means parking sensor wiring, radar units for adaptive cruise control, and front camera systems are undisturbed unless you later add a bumper upgrade.

Side Skirt Flares: Connecting the Wide Stance Front to Rear

Side skirts are the element that transforms isolated arch flares into a cohesive wide body styling statement. Without skirts, flared arches look like accessories bolted on. With skirts, the van reads as a single designed object with a deliberate, lower silhouette.

Our Mercedes Sprinter W907 side skirts in ABS plastic are designed to align with the lower door sill and connect visually to the arch flare profiles we produce for the same generation. The mounting method uses existing body holes plus additional adhesive bonding points, which keeps the installation reversible if you later sell or return the van to standard.

For W906 owners, we produce a matching side skirt set for the 2006-2018 platform. Both sets are available for standard wheelbase and long wheelbase configurations.

Sensor and ADAS Compatibility for 2025 Builds

Modern Sprinter vans, particularly the W907/VS30 built from 2019 onward, carry a significant amount of driver assistance hardware in the bodywork: front radar for adaptive cruise control, parking sensors front and rear, reversing cameras, and on some configurations, a 360-degree surround view system. Wide body styling parts must account for all of this.

Arch flares on the front corners must clear the front parking sensor positions. Rear arch flares must not obstruct the ultrasonic sensors or the camera housing if fitted. Our W907 arch flares are designed with the VS30 sensor layout in mind, and we include guidance on sensor relocation where required.

In Europe, if arch flares or body additions change the overall vehicle width beyond the homologated figure on the V5C or Fahrzeugschein, the modification may require a TUV or equivalent national type approval endorsement. We hold TUV certificates for selected products, and we advise customers in Germany, the Netherlands, and other strict-inspection markets to check which certificate applies to their chosen parts before ordering.

Shipping, VAT and Customs for US and European Buyers

DL Auto Design ships worldwide from Lithuania. For US buyers (where the W907 is sold as the VS30 Sprinter 2500 and 3500), parts ship internationally and may be subject to import duties depending on the declared value and current trade arrangements. We document all shipments accurately and can advise on HS codes for customs clearance upon request.

For buyers inside the European Union, VAT applies at the Lithuanian rate and is collected at checkout. For buyers outside the EU - including US, UK, South Korean, and other non-EU customers - 0% VAT applies, which is a real cost saving on higher-value orders such as a full arch flare and side skirt set. This is calculated automatically at checkout based on your delivery country.

Returns are accepted for unused, unmodified parts in original packaging. Because many of our products are custom-manufactured or pre-painted to order, we recommend confirming all fitment details before purchase using the generation and wheelbase information above.

Wide Look vs Full Body Kit: Which Is Right for Your Build?

A full body kit replaces the front bumper, rear bumper, side skirts, and often the grille as a matched set for a complete aesthetic transformation. A wide look kit prioritises arch flares and side skirts to achieve stance and width, leaving bumpers optional. The table below summarises the practical differences.

Frequently Asked Questions

Do arch flares for the W907 fit the US-market VS30 Sprinter?

Yes. The W907 and VS30 are the same platform. Our arch flares and side skirts listed for W907 fit the 2019-to-present Sprinter 2500, 3500, and 3500XD sold in the United States, subject to wheelbase confirmation.

Will I need to cut the bodywork to fit fender flare extensions?

In most cases, no. Our arch flares are designed to overlay the existing body using bonding adhesive and supplementary fixings. Sheet metal trimming is occasionally needed on W906 models where tyre clearance is very tight, but W907 fitments typically require no cutting.

What material should I choose for a camper van or off-road Sprinter build?

We recommend ABS plastic for camper and off-road builds. ABS absorbs minor impacts and trail debris without cracking, holds up to temperature cycles better than FRP in outdoor environments, and is easier to repair in the field.

Do your arch flares have TUV certification?

TUV certificates are available for selected products in our range. Contact us before ordering if you are in Germany or another EU market that requires type approval documentation, and we will confirm which certificate applies to your chosen parts.

Can I order the arch flares and side skirts pre-painted?

Yes. We offer pre-painted parts when you supply your Mercedes paint code or RAL colour reference at the time of order. Pre-painted parts are ready to install without a local body shop step, though we recommend a professional paint and lacquer inspection before final fitting.

How does the 0% VAT work for non-EU buyers?

If your delivery address is outside the European Union - for example in the United States, the United Kingdom, or South Korea - the EU VAT is automatically removed at checkout. The price you pay is the net price only. Import duties in your destination country are separate and are the buyer's responsibility.

Can I fit side skirts on a long-wheelbase L3 or L4 Sprinter?

Yes. We produce side skirts sized for both standard and long wheelbase configurations on W906 and W907. Specify your wheelbase code when ordering to receive the correctly dimensioned set.

Achieving a wide, planted stance on your Mercedes Sprinter does not require a full bumper-to-bumper body kit. A well-chosen combination of arch flares and side skirts from DL Auto Design delivers genuine wide body styling on W906, W907, and W910 platforms, in ABS or fiberglass, with worldwide shipping and 0% VAT for non-EU buyers. Browse our current range at dlautodesign.com and use the generation and wheelbase filters to find the exact parts for your build in 2025.
